20mA Energy Meter Testing Equipment , ZnO Surge Arrester Tester
Product Summary
ZnO Surge Arrester On-line Tester MCZA 6820 Function & Character LCD display High accuracy sampling, processing, Advanced Fourier harmonic analysis, Reliable data Directly collecting signal of voltage and current. 3,5,7 times harmonic test, harmonic wave With resistive current basic wave peak output ...
Product Custom Attributes
Application:
Worksite, Online
Test Range:
0-20mA
Power Supply:
220V+/-10% And Rechargeable Battery
Harmonic Order:
3, 5, 7
Highlight:
20mA Energy Meter Testing Equipment
,220V Energy Meter Testing Equipment
,ZnO Surge Arrester Tester
Basic Properties
Place of Origin:
China
Brand Name:
HNMC
Model Number:
MCZA 6820
Trading Properties
Minimum Order Quantity:
1
Price:
Negotiable
Packaging Details:
wooden package
Delivery Time:
4-8weeks
Payment Terms:
L/C, T/T, Western Union,
Supply Ability:
50 sets per month
Product Description
ZnO Surge Arrester On-line Tester MCZA 6820
Function & Character
- LCD display
- High accuracy sampling, processing, Advanced Fourier harmonic analysis, Reliable data
- Directly collecting signal of voltage and current.
- 3,5,7 times harmonic test, harmonic wave
- With resistive current basic wave peak output function
- Having inbuilt memory, abble to store 50 groups test records
- With USB Port
- With preventing wrong connection function
- With wireless transmit, acquisition
- Inbuilt high accurate o’clock
- With high speed thermal printer for testing result printing at workste
- With rechargeable battery as power supply
Technical Index
1.voltage and current parameter :
| Test item | Test range | Test accuracy | |
| Full current | 0-20mA | ±(readingX5%＋5µA) | |
| Resistive current | 0-20mA | ±(readingX5%＋5µA) | |
| Capacitive current | 0-20mA | ±(readingX5%＋5µA) | |
| Current harmonic | 0-20mA | ±(readingX10%＋10µA) | |
| Reference voltage | Max.100V RMS | ±(readingX5%＋0.5V) | |
| Voltage harmonic | Max.100V RMS | ±(readingX10%) | |
| transmitting distance | apparent 500m | ||
| Power supply | AC220V±10%, 50HZ / Rechargeable Battery (can continuously work for 6 hour or more after 3-hour charging | ||
| Dimension | 320*260*135mm | ||
| work temperature | -10℃-40℃ | ||
| Relative humidity | ≤85% non condensing | ||
| Storage temperature | -20℃-50℃ | ||
| Weight | approx 5.0KG | ||
Packing list
| 1 | Host machine | 1 No | 6 | Charger | 1 No |
| 2 | Wireless module | 1 No | 7 | Print paper | 1 Roll |
| 3 | Air wire | 2 Nos | 8 | Use manual | 1 copy |
| 4. | Test cable | 1 set | 9 | Routine report | 1 copy |
| 5 | Fuse (0.1A) | 4 pcs |
