Three Phase Protection Relay Test Equipment LCD Display

Name: Three Phase Protection Relay Test Equipment LCD Display
Brand: Zhengzhou Great Electric Co.,Ltd.
SKU: MCRT40
Availability: InStock

Product Summary

4 Phase voltage & 3 Phase current output Protection Relay Test Equipment With Fault Playback Main test of software interface Technical Index of 4 Phase voltage & 3 Phase current output, AC current source Output accuracy 0.5% Output range 3*(0-40A); 0-120A (three phases in parallel) Phase current ...

Product Custom Attributes

Voltage Range:

4*(0-120V)

Current Range:

3*(0-40A)

Output Accuracy:

0.5%

Display:

LCD

Voltage:

4 Channels

Current:

3 Channels

Highlight:

Three Phase Protection Relay Test Equipment

LCD Protection Relay Test Equipment

LCD protective relay test set

Basic Properties

Place of Origin:

China

Brand Name:

HNMC

Model Number:

MCRT40

Trading Properties

Minimum Order Quantity:

Price:

Negotiable

Packaging Details:

wooden package

Delivery Time:

4-8weeks

Payment Terms:

L/C, T/T, Western Union,

Supply Ability:

50 sets per month

Tags:

Product Description

4 Phase voltage & 3 Phase current output Protection Relay Test Equipment With Fault Playback

Main test of software interface

Three Phase Protection Relay Test Equipment LCD Display

Technical Index of 4 Phase voltage & 3 Phase current output,

AC current source
Output accuracy	0.5%
Output range	3*(0-40A); 0-120A (three phases in parallel)
	Phase current which can get long-time working 10A
	Maximum output power of phase current: 420VA
	Maximum output power of three phase current in parallel: 900VA
	Permissible working time (when three phase current in parallel to get maximum output): 10s
Frequency (basic wave) range	20-1000Hz
Harmonics times	1-20 times
DC current source
Output accuracy	0.5%
Current output	0-+/-10A per phase; 0-+/-30A (three phase in parallel)
Maximum load voltage output	20V
Output accuracy	0.5%
Phase voltage output	4*(0-120V)
Line voltage output	0-240V
Phase voltage/line voltage output power	80VA/100VA
Frequency (basic wave) range	20-1000H
Harmonics	1-20 times
DC voltage source
Output accuracy	0.5%
Phase voltage output amplitude	0-+/-160V
Line voltage output amplitude	0-+/-320V
Phase voltage/line voltage output power	70VA/140VA
Dimension	400300180mm
Weight	approx 20KG
Power supply	AC 220V±10%,50／60Hz
Ambient temperature	-10℃ ～ +50℃

Switch signal and time measurement

Switch signal input

7circuits

Idle contact: 1～20mA,24V

Potential contact access: “0”:0～ +6V； “1”:+11 V～ +250V

Switch signal output

2 pairs

DC:220V／0.2A；AC:220V／0.5A

Time measure

Test range: 0.1ms ～ 9999s , accuracy 0.1mS

Measurement range: 0.1ms ～ 9999s

Measurement accuracy:0.1mS

Three Phase Protection Relay Test Equipment LCD Display
