15T Ohm Insulation Resistance Test Set Anti Interference
Product Summary
Insulation Dielectric Test -Insulation Resistance Tester 5kV MCRT005 Main Features 1. 32-bit micro-controller, English interface, easy to operate. 2. Automatically calculates the absorption ratio and the polarization index, and automatically save 15 seconds, 1 minute, 2 minutes,10 minutes to ...
Product Custom Attributes
Display:
LCD
Voltage Range:
Up To 5KV
Test Range:
0.1M ~ 15TΩ
Power Supply:
180-270V AC
Application:
Worksite, Lab
Short Circuit Current:
≧5mA
Highlight:
5KV Insulation Resistance Test Set
,15T ohm Insulation Resistance Test Set
,worksite dielectric resistance test
Basic Properties
Place of Origin:
China
Brand Name:
HNMC
Model Number:
MCRT005
Trading Properties
Minimum Order Quantity:
1 pc
Price:
Negotiable
Packaging Details:
Carton package
Delivery Time:
20-25 Days
Supply Ability:
25 pcs per month
Product Description
Insulation Dielectric Test -Insulation Resistance Tester 5kV MCRT005
Main Features
1. 32-bit micro-controller, English interface, easy to operate.
2. Automatically calculates the absorption ratio and the polarization index, and automatically save 15 seconds,
1 minute, 2 minutes,10 minutes to facilitate analysis of data per minute.
3. Output current and short-circuit current are greater than 5mA.Anti-interference ability, which meets
the EHV substation on-site operation.
4. With a fully enclosed high-voltage generator module technology,and the protection of the internal
resistance is safe and reliable.
5. Automatic discharge after testing and real-time monitoring the discharge process
Technical Parameter
| Item | Technical Index |
| Accuracy | ± 10% |
| Range | 0.1M ~ 15TΩ |
| Test Voltage | 0.5KV,1KV,2.5KV,5KV |
| Short Circuit Current | ≧5mA |
| Measuring Time | 1 minute to 10 minutes |
| Power Supply | 180 ~ 270VAC, 50Hz/60Hz ± 1% |
| Working Environment | -10～40℃ |
| Humidity | 20～80％ |
Packing List
| No. | Item | Qty |
| 1 | Main device | 1 |
| 2 | Red test cable | 1 |
| 3 | Test cable | 1 |
| 4 | Power cord` | 1 |
| 5 | Ground cable | 1 |
After sales service
- Our sales and technical team can guarantee a fast and highly efficient after sales service for our products sold.
- Once problem happens in clients, firstly we will consider online support of our clients to solve it quickly; secondly we will consider to provide spare parts for client to replace after fixing reason.
We will provide best service to support your marketing field.
Contact Our Experts And Get A Free Consultation!
Our mission is to offer "High Quality" & "Good Service" & "Fast Delivery" to help our clients to gain more profits.
