100KV Oil Dielectric Strength Tester , 80%RH Dielectric Strength Test Equipment
Product Summary
Insulation Oil Dielectric Strength Test Set MCOT300 Main Features With microprocessor, automatically fulfill the withstand-voltage test of insulating oil LCD display With in-built thermal printer, which can print each breakdown and average voltage value Can save 100 group test results Make a choice ...
Product Custom Attributes
Voltage Test Range:
0-100KV
Display:
LCD
Input Supply:
220V+/-10%
Weight:
28KGS
Insulation Cup:
3 Cups
Data Store:
100 Goups
Highlight:
100KV Oil Dielectric Strength Tester
,220V Oil Dielectric Strength Tester
,80%RH Dielectric Strength Test Equipment
Basic Properties
Place of Origin:
China
Brand Name:
HNMC
Model Number:
MCOT300
Trading Properties
Minimum Order Quantity:
1 pc
Price:
Negotiable
Packaging Details:
Composite Board package
Delivery Time:
20-25 Days
Supply Ability:
50 sets per month
Product Description
Insulation Oil Dielectric Strength Test Set MCOT300
Main Features
- With microprocessor, automatically fulfill the withstand-voltage test of insulating oil
- LCD display
- With in-built thermal printer, which can print each breakdown and average voltage value
- Can save 100 group test results
- Make a choice for combination at random between A, B, and C cup
Technical parameters
| Item | Technical Index |
| Input voltage | AC 220V±10% |
| Output voltage | AC 0~100KV |
| Rate of voltage rise | 2KV/s±10% |
| Measuring precision | 2KV/s±10% |
| Continuously test Times | 1-6 |
| Mixing time | 0~99 seconds |
| Placing time | 0-9 minute 59seconds |
| Voltage limit setting for proof test | 20KV----75KV |
| Voltage withstand time | 0 -10 minutes |
| Environment temperature | 5-40℃ |
| Relative humidity | ≤80%RH |
| Size | 430×390×420mm |
| Weight | 28kgs |
